Cushcraft A270-10S Dualband Beam Antenna

Cushcraft A270-10S Dualband Beam Antenna

MPN: A270-10S

$374.00

Please note: Due to the size of this antenna, it can only ship via UPS and extra shipping charges will apply.

Out of Stock (On Order)

Get notified when this product is back in stock

SKU: 13552 Category:

Beam, Dualband, 5el + 5el 2m, 70cm, 10, 10, One Boom

Increase your range by selecting Cushcrafts dual band Yagi. You can point the antenna at stations while you are in QSO with them. This will direct more of your output power when transmitting at the same time reducing interference and increasing signal strength when receiving. These antennas are perfect for packet applications. Assembly is a snap with our fully illustrated assembly manuals.

Weight 5.24 lbs
Dimensions 58 × 4.75 × 2.5 in
Brand

Cushcraft
Manufacturer Part Number A270-10S

Specifications

Cushcraft A270-10S Specifications
Frequency, MHz:
144-148 430-450
No. Elements:
5 / 5
Forward Gain, dBi:
10 / 10
Front to Back Radio, dB:
20 / 18
SWR 1.2:1 Typical
2:1 Bandwidth, MHz
4 / 10
Power Rating, Watts PEP:
350 / 350
3 dB Beamwidth, Degees
E Plane
H Plane
52 / 52
60 / 60
Boom Length, ft (m):
6.17 (1.9)
Longest Element, in (cm):
40.3 (102.4)
Turning Radius, ft (m):
6 (1.8)
Mast Size Range, in:
1.25 – 2
Wind Load, ft sq (m sq)
.725 (.07)
Weight, lb (kg)
1.8 (.81)

Documentation

Cushcraft A270-10S Install Instructions
