Cushcraft A13B2 3 Element Wideband Boom Antenna

Cushcraft A13B2 3 Element Wideband Boom Antenna

MPN: A13B2

$583.00

Please note: Due to the size of this antenna, it can only ship via Purolator and extra shipping charges will apply.

Out of Stock (On Order)

Get notified when this product is back in stock

SKU: 13853 Category:

2-M, YAGI, 13 ELE, 18.5DBI, 1.5KW

A13B2 will be your choice for high performance across the entire 2 meter band. New and experienced hams will enjoy 15.8 dBi gain on FM, packet, CW, or sideband across the 4 MHz operating range.

The A13B2 is easily mounted vertically or horizontally for maximum performance on your favorite mode. Its optimum boom length makes it a popular antenna that fits just about anywhere. The new UltraMatch balanced feed on the A13B2 provides a 50 Ohm match via a standard SO-239 UHF female connector.

Weight 6.7 lbs
Dimensions 78 × 3 × 5 in
Brand

Cushcraft
Manufacturer Part Number A13B2

Specification

Cushcraft A13B2 Specifications
Frequency, MHz:
144-148
No. Elements:
13
Forward Gain, dBi:
15.8
Front to Back Radio, dB:
26
SWR 1.2:1 Typical
2:1 Bandwidth, MHz
>4
Power Rating, Watts PEP:
1500
3 dB Beamwidth, Degees
E Plane
H Plane
2 x 18
2 x 19
Side Lobe Atten., dB, E Plane:
>60
Boom Length, ft (m):
15 (4.57)
Electrical Wavelength:
2.2
Longest Element, in (cm):
39.75 (101)
Turning Radius, ft (m):
8.9 (2.7)
Mast Size Range, in (cm):
1.5 – 2 (3.8 – 5.1)
Wind Load, ft sq (m sq)
1.8 (.17)
Weight, lb (kg)
6.7 (0.31)

Product Guides & Documentation

Cushcraft A13B2 Assmbly and Installation Instructions
